RDP Reciprocating Pumps

Reciprocating Triplex and Quintuplex Plunger Pumps

The RDP range is a series of Reciprocating Plunger Pumps in a variety of sizes in Triplex and Quintuplex formats and designed in accordance with the latest edition of API 674 and ISO 13710 for high pressure applications.

Operation limits

Capacity up to 366.50 m³/h (1611 gpm)

Pipe Size 25 to 200 mm (1 to 8 in)

Maximum Pressure up to 1100 barg

Temperature -40 to 200 °C (-104 to 392 °F)

Speed up to 450 rpm

Applications Methanol Injection, Carbon Dioxide (CO2), Glycol Circulation, Sea Water Injection, Produced Water Disposal, Reverse Osmosis (seawater desalination), Water Treatment, Production and Jetting, Hydrocarbon (Condensate), Closed Drain Pumps, Slops Injection, Boiler Feed, Fertiliser (Carbamate & Ammonia), Steel Plants (high pressure descaling), Blow Out Preventer (BOPV) actuation, Flowline Circulation, Pipeline Pigging, Synthetic and Renewable fuels.


The RDP series of Reciprocating Plunger Pumps is suitable for handling most liquids for Oil & Gas, Industrial and Wastewater Treatment applications. RP's RDP pump series are a type of positive displacement pumps where a smooth cylindrical plunger slides through the seal, making it different from piston pumps and allowing higher pressures.

  • A variety of sizes in Triplex and Quintuplex formats
  • Designed in accordance with API 674 3rd edition and ISO 13710
  • Easily accessible service points reducing maintenance time
  • Robust design for low noise and vibrational characteristics
  • High duty efficiency
  • Extensive range capability
  • Design life of 20 years
  • Excellent noise and vibration characteristics < 85dB(A)
  • 95% volumetric and 90% mechanical efficiency, exceeding API standards
  • Stuffing box can be removed without pump disassembly
  • Spring loaded, auto adjustment braided compression and chevron packing, minimizes leakage
  • Valves in cartridge, easy removal and replacement
  • Configurable for drives, lubrication and skids
  • Crankcase in ductile iron with customer specific paint finish
  • Wetted parts can be made from a wide range of alloys including NACE and NORSOK compliance
  • All materials provided are high quality and NDT can be tailored to meet the project’s requirements
  • Can be manufactured to meet specific specifications such as:
    • NORSOK
    • ASME
    • SHELL ES 135
    • Statoil TR1655
    • ...and many more
  • Dampeners, PSV's and instrumentation can mount directly to pump head
  • Motor can mount directly to top of crankcase for compact offshore footprint
  • ATEX compliance
  • Package condition monitoring
  • Various seal and power end lubrication options
  • Electric motor
  • Diesel or petrol engine
  • Hydraulic motor
  • Variable speed drive
  • Various transmission options including: Gearbox / V-belt drives


Reciprocating Plunger Pump Performance Chart by RP

For applications outside the Operation Limits, please contact RP.
